Heavy AMHS Trolley OTS-823-001

Description

Key Points:-

• Automated overhead transport vehicle (Model OTS-823-001) for industrial logistics.

• Operates on an elevated track network with a R1000 mm turning radius.

• Back-mounted elevator lifting system supports payloads up to 500 kg and lift heights up to 3,000 mm.

• Reaches travel speeds up to 120 m/min and lifting speeds up to 30 m/min.

• Delivers 5 mm walking positioning accuracy and 1 mm lifting positioning accuracy.

• Powered continuously via slide contact line to eliminate battery charging downtime.

• Connects via Wi-Fi and PLC to WMS, MES, or enterprise platforms.

• Functions in temperatures from 0°C to 40°C and non-condensing humidity up to 90%.

The Heavy Duty Aerial Vehicle (Model OTS-823-001) is a high-capacity, automated overhead transport solution distributed in Singapore by JEC Technology. Designed for demanding industrial environments such as automotive manufacturing and new energy production, this robust system moves heavy payloads along an elevated track network to overcome ground-level layout constraints. By transitioning heavy material movement off factory floors and into vertical airspace, facilities optimize space usage and eliminate ground-level transportation bottlenecks.

Engineered to handle significant operational demands, the OTS-823-001 delivers a rated load capacity of up to 500 kg using a back-mounted transport design paired with a reliable elevator lifting system. Operating smoothly at travel speeds reaching 120 meters per minute and lifting speeds up to 30 meters per minute, it ensures high-throughput cargo delivery across complex facility layouts. Constructed for durable industrial performance, the system functions seamlessly within temperature ranges of 0°C to 40°C and non-condensing humidity environments up to 90%.

Through JEC Technology, businesses receive local distribution support, continuous supply reliability, and expert integration guidance tailored to local manufacturing standards. This smart three-dimensional logistics solution provides enterprises with a seamless pathway toward building fully automated, high-efficiency production environments.

Product Features

High Precision & Superior Positioning

Equipped with advanced navigation controls, the vehicle achieves a precise walking positioning accuracy of 5 mm and an exceptional lifting accuracy of 1 mm. Its specialized back-mounted elevator lifting system supports vertical lift heights up to 3,000 mm, ensuring accurate automated docking and alignment at loading stations. Additionally, a tight turning radius of R1000 mm allows flexible integration into complex, space-constrained facility layouts.

Seamless Connectivity & Continuous Power

Designed for smart factory integration, the OTS-823-001 supports industrial-grade Wi-Fi and PLC communication interfaces, allowing real-time closed-loop monitoring and integration with central WMS, MES, or third-party enterprise platforms. Power is delivered continuously via a slide contact line, eliminating battery charging downtime and supporting round-the-clock uninterrupted operational cycles.

Sustainable & Customized Operation

Built to lower carbon emissions and energy consumption, the system significantly reduces operational noise and workplace environmental impact compared to conventional forklift transport. The track infrastructure, carrier shuttle counts, and loading points can be configured on demand to meet specific enterprise production goals. Supported by JEC Technology in Singapore, clients benefit from end-to-end installation consultation, system configuration, and dedicated local technical support.
