USB Series Soldering Tips
Description
Key Points:-
-
Specialized flat-type soldering tips (USB Series, including USB 8mm, USB 10mm, and 911G/USB 11.0mm × 2.0mm, 12.0mm × 2.0mm, and 13.0mm × 2.0mm) engineered specifically for automated and semi-automated multi-pin connector soldering.
-
Wide, flat contact face geometry enables simultaneous multi-pin soldering across all connector pins in a single 3-to-4-second cycle, significantly increasing production throughput over single-pin manual methods.
-
Tailored connector dimensions match standard formats, including USB Type-A, Type-C, Micro-USB, and wire harness terminals.
-
High-conductivity core delivers uniform surface temperature across the entire tip width, eliminating localized cold spots.
-
Pre-tinned flat surface ensures even solder distribution across all connector pins without causing solder bridges.
-
Essential consumable tips for high-volume cable assembly lines, consumer device manufacturing, and wire harness production.
The USB Series encompasses specialized flat-type soldering tips engineered specifically for automated and semi-automated multi-pin connector soldering. Designed with wide, flat contact faces matching standard connector layouts, these tips allow operators or machines to solder multiple pins simultaneously in a single 3-to-4-second cycle. This multi-point capability drastically increases production throughput compared to single-pin manual methods.
Available in standard widths—such as USB 8mm, USB 10mm, and 911G/USB series (11.0mm x 2.0mm, 12.0mm x 2.0mm, and 13.0mm x 2.0mm)—these tips cover various connector formats including USB Type-A, Type-C, Micro-USB, and wire harness terminals. The pre-tinned flat surface ensures even solder distribution across all connector pins without bridging. They are essential consumables for high-volume cable assembly and consumer device manufacturing.
Features
Featuring a wide flat face geometry available in dedicated widths from 8mm to 13mm, this tip enables simultaneous soldering across all connector pins in 3 to 4 seconds to match specific USB Type-A, Type-C, and harness specs. Its high-conductivity core maintains uniform surface temperatures across the entire tip width, eliminating localized cold spots during operation.
